Sandvik Coromant
CNMG 09 03 04-MF 1125 Carbide Insert, Grade 1125, TiAlN - Sandvik Coromant 6292960
MFR# 6292960ISO/ANSI# CNMG 09 03 04-MF 1125Series T-Max P
$12.76List $16.36
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC3/8
ShapeDiamond
Grade1125
MaterialCarbide
CoatingTiAlN
Description
The Sandvik Coromant 6292960 is a CNMG 09 03 04-MF 1125 carbide indexable insert, grade 1125, TiAlN coated. Suited for steel.
Specifications
Chip breakerMF
Clearance codeN
Coating finishTiAlN
Coating processPVD
Corner radius in1/64
Hole diameter0.1500
Included angle80
Inscribed circle in3/8
Insert handNeutral
Insert holding methodClamp; Pin
Insert length0.3807
Insert materialCarbide
Insert shapeDiamond
Insert size code321
Insert styleCNMG
Insert thickness in1/8
Iso codeCNMG 09 03 04-MF 1125
Length range0.3000 - 0.4000
Manufacturers catalog number6292960
Manufacturer grade1125
Maximum depth of cut0.3650
Number of cutting edges4
Primary workpiece materialSteel
Relief angle0
Secondary workpiece materialSteel; Stainless Steel; Superalloy; Titanium
Tolerance codeM
Wiper edgeNo
