Sandvik Coromant
CNMM 12 04 12-PR 4425 Carbide Insert, Grade 4425, TiCN - Sandvik Coromant 7860733
MFR# 7860733ISO/ANSI# CNMM 12 04 12-PR 4425Cat# CNMM 433-PR 4425Series T-Max P
$17.31List $22.20
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
ShapeDiamond
Grade4425
MaterialCarbide
CoatingTiCN
Description
The Sandvik Coromant 7860733 is a CNMM 12 04 12-PR 4425 carbide indexable insert, grade 4425, TiCN coated. Suited for steel.
Specifications
Chip breakerPR
Clearance codeN
Coating finishTiCN
Coating processCVD
Corner radius0.0469
Hole diameter0.2030
Included angle80
Inscribed circle0.2030
Insert handNeutral
Insert holding methodClamp; Screw
Insert materialCarbide
Insert shapeDiamond
Insert size code1204
Insert styleCNMM
Insert thickness in3/16
Iso codeCNMM 12 04 12-PR 4425
Manufacturers catalog numberCNMM 433-PR 4425
Manufacturer grade4425
Number of cutting edges2
Primary workpiece materialSteel
Relief angle0
Secondary workpiece materialCast Iron
Tolerance codeM
Wiper edgeNo
