Sandvik Coromant
CNMG 12 04 04-SM S205 Carbide Insert, Grade S205, Al2O3 - Sandvik Coromant 8003625
MFR# 8003625ISO/ANSI# CNMG 12 04 04-SM S205Cat# CNMG431-SMSeries T-Max P
$21.33List $26.89
Save 20%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
⚡ Need it urgently? Confirm stock & ship time →
Supplier prices are confirmed before checkout. If one has changed since this page was updated, we show you the new price before you pay.
Request a quote- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeTriangle
GradeS205
MaterialCarbide
CoatingAl2O3
Description
The Sandvik Coromant 8003625 is a CNMG 12 04 04-SM S205 carbide indexable insert, grade S205, Al2O3 coated.
Specifications
Chip breakerG
Clearance codeN
Coating finishAl2O3
Coating processCVD
Corner radius0.0156
Included angle80
Industry standard numberCNMG 12 04 04-SM S205
Inscribed circle in1/2
Insert handNeutral
Insert holding methodClamp; Screw
Insert materialCarbide
Insert shapeTriangle
Insert size code120404
Insert styleCNMG
Insert thickness in3/16
Iso codeCNMG 12 04 04-SM S205
Manufacturers catalog numberCNMG431-SM
Manufacturer gradeS205
Relief angle0
Tolerance codeM
