Sandvik Coromant
CNMU 12 04 12-PM 4425 Carbide Insert, Grade 4425, TiCN - Sandvik Coromant 8019698
MFR# 8019698ISO/ANSI# CNMU120412Cat# CNMU 12 04 12-PM 4425Series CNMU-PM
$20.67List $26.51
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeC - Diamond (Rhombic) 80-Deg
Grade4425
MaterialCarbide
CoatingTiCN
Description
The Sandvik Coromant 8019698 is a CNMU 12 04 12-PM 4425 carbide indexable insert, grade 4425, TiCN coated.
Specifications
Ansi insert codeCNMU433
Ansi size code433
Chip breakerPR
Chip breaker operationRoughing; Medium Machining
Clearance codeN
Coating finishTiCN
Coating processCVD
Corner radius0.0469
Grade characteristicsSteel (P) - High Wear-Resistance to Moderate Wear-Resistance and Toughness
Inscribed circle in1/2
Insert handNeutral
Insert holding methodClamp; Screw
Insert materialCarbide
Insert shapeC - Diamond (Rhombic) 80-Deg
Insert size code433
Insert styleCNMU
Insert thickness in3/16
Iso codeCNMU 12 04 12-PM 4425
Iso insert codeCNMU120412
Iso size code120412
Manufacturers catalog numberCNMU 12 04 12-PM 4425
Manufacturer grade4425
Relief angle0
Side clearanceNegative
Tolerance codeM
