Sandvik Coromant
CNMU 12 04 12-PM 4415 Carbide Insert, Grade 4415, TiCN - Sandvik Coromant 8021312
MFR# 8021312ISO/ANSI# CNMU 12 04 12-PM 4415Cat# CNMU 12 04 12-PM 4415Series CNMU-PM
$18.70List $23.98
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
Grade4415
MaterialCarbide
CoatingTiCN
Description
The Sandvik Coromant 8021312 is a CNMU 12 04 12-PM 4415 carbide indexable insert, grade 4415, TiCN coated.
Specifications
Chip breakerPM
Clearance codeN
Coating finishTiCN
Coating processCVD
Corner radius0.0469
Inscribed circle in1/2
Insert handNeutral
Insert holding methodClamp; Screw
Insert materialCarbide
Insert size code433
Insert styleCNMU
Insert thickness in3/16
Iso codeCNMU 12 04 12-PM 4415
Manufacturers catalog numberCNMU 12 04 12-PM 4415
Manufacturer grade4415
Relief angle0
Tolerance codeM
