Seco
Indexable Turning & Profiling - Seco 00002850
MFR# 00002850Series Multi-Directional Turning (MDT)
$256.18List $272.16
Save 5%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Seco 00002850 indexable turning & profiling. Suited for universal. Series Multi-Directional Turning (MDT).
Specifications
Back of bar to cutting edge1.0000
Compatible insert size codeLC1603
Complete insert compatibilityLC.. 1603..; LCGN; LCMF; LCMR
Coolant throughNo
Cutting directionLeft Hand
Cutting tool applicationCut-Off; Grooving
Hand of holderLeft Hand
Head length1.1400
Insert compatibilityLC..1603..
Insert holding methodClamp
Insert width0.1180
Lead angle90.0
Multi use toolYes
Overall length in4-1/2
Primary workpiece materialUniversal
Shank height in3/4
Shank width in3/4
Toolholder materialSteel
Toolholder styleCFML
