Seco
Carbide Insert, Grade F30M, TiAlN - Seco 00023735
MFR# 00023735Series MM06
$83.70
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes3
GradeF30M
CoatingTiAlN
Description
The Seco 00023735 is a carbide indexable insert, grade F30M, TiAlN coated. Suited for steel, non-ferrous metal, hard material.
Specifications
Chamfer angle0degree
ChipbreakerE02
Coating finishTiAlN
Coating processPVD
Coolant throughYes
Corner radius0.0000
Cutting width0.2500in
Extension from holder in0.3900
Functional length0.3900
Helix angle30
Included angle degree90
Insert handRight Hand
Insert size0.250-A30
Lead angle90
Length of cut0.2950in
Manufacturers catalog number00023735
Manufacturer gradeF30M
Material gradeP20; P30; H10
Maximum depth of cut0.2950
Milling tip full descriptionMM06-0.250-A30-E02
Milling tip styleMM06
Milling tip typeSlotting
Number of flutes3
Overall length0.3900in
Primary workpiece materialSteel; Non-Ferrous Metal; Hard Material
StandardsANSI
Tool materialCarbide
