Carbide Insert, Grade UNSPEC, TiAlN - Seco 00059683

Seco

Carbide Insert, Grade UNSPEC, TiAlN - Seco 00059683

MFR# 00059683Series Crownloc

$182.99List $194.40 Save 5%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Flutes2
GradeUNSPEC
CoatingTiAlN

Description

The Seco 00059683 is a carbide indexable insert, grade UNSPEC, TiAlN coated. Suited for stainless steel, non-ferrous metal, superalloys & titanium, hard material.

Specifications

Coating finishTiAlN
Coating processPVD
Coolant throughNo
Cutting diameter0.6693
Drill point angle140
Flute length (mm)10.00
Flute typeHelical
Functional length0.3990
Height0.5236
Included angle degree140
Insert geometryM
Insert holding methodClamp
Iso numberSD100-17.46-M
Manufacturer gradeUNSPEC
Number of flutes2
Overall length projection0.5240
Point typeStandard
Primary workpiece materialStainless Steel; Non-Ferrous Metal; Superalloys & Titanium; Hard Material
Spiral typeRegular Spiral
StyleCrownloc
Tip materialSolid Carbide
