Seco
RCGS4.76-46 Carbide Insert, Grade CP200, TiAlN - Seco 00072263
MFR# 00072263ISO/ANSI# RCGS4.76-46Series T-Lock
$28.11List $36.06
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC3/16
GradeCP200
MaterialCarbide
CoatingTiAlN
Description
The Seco 00072263 is a RCGS4.76-46 carbide indexable insert, grade CP200, TiAlN coated. Suited for steel, stainless steel, superalloys & titanium, hard material.
Specifications
ApplicationsProfiling; Turning
Chipbreaker46
Coating finishTiAlN
Coating processPVD
Corner radius0.0937
Hole diameter0.0000
Included angle360
Inscribed circle in3/16
Insert handNeutral
Insert height0.2500
Insert holding methodClamp; Pin
Insert length in3/16
Insert materialCarbide
Insert size code1.5
Insert styleRCGS
Iso codeRCGS4.76-46
Manufacturer gradeCP200
Material gradeP10; P20; M01; M10; M20; S10; S20
Maximum depth of cut0.0937
Msc manufacturer numberRCGS1.5-46
Number of cutting edges4
Primary workpiece materialSteel; Stainless Steel; Superalloys & Titanium; Hard Material
RakePositive
Relief angle7
Secondary workpiece materialCast Iron; Steel
ShapeRound
Side length0.1874
StandardsRCGS1.5-46; RCGS4.76-46
Thickness in1/4
Width in3/16
