Seco
OFMT050405TR-M14 Solid Carbide Insert, Grade F40M, TiAlN - Seco 00077640
MFR# 00077640ISO/ANSI# OFMT050405TR-M14Cat# OFMT050405TR-M14Series OFMT-05
$22.66List $29.06
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
ShapeOctagon
GradeF40M
MaterialSolid Carbide
CoatingTiAlN
Description
The Seco 00077640 is a OFMT050405TR-M14 solid carbide indexable insert, grade F40M, TiAlN coated. Suited for steel, cast iron, superalloys & titanium.
Specifications
Ansi codeOFMT050405TR-M14
Chip breakerM14
Coating finishTiAlN
Coating processPVD
Corner radius0.0197
Cutter series compatibilityR217.43-05; R220.43-05
Cutting edge effective length0.2161
Cutting edge styleT-Land
Hole diameter0.1772
Included angle degree135
Inscribed circle0.5189
Inscribed circle range0.5100 to 0.6000
Insert handRight Hand
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeOctagon
Insert size05
Insert size code050405
Insert styleOFMT
Iso codeOFMT050405TR-M14
Length0.5189
Length range0.5000 to 0.6000
Manufacturers catalog numberOFMT050405TR-M14
Manufacturer gradeF40M
Material applicationSteel; Stainless Steel; Cast Iron; Non-Ferrous Metal; Superalloys & Titanium
Material gradeFine Grain
Maximum depth of cut0.1063
Multi use toolYes
Number of cutting edges8
Primary workpiece materialSteel; Cast Iron; Superalloys & Titanium
RakeNeutral
Rake angle0
Relief angle26
Secondary workpiece materialCast Iron; Non-Ferrous Metal
ShapeOctagon
Single or double sided insertSingle
StandardsISO
Thickness in3/16
Thickness range0.1850 to 0.2000
Width0.5189
