Seco
1/4" IC Solid Carbide Insert, Grade CP500, Coated - Seco 00077959
MFR# 00077959Series Snap Tap
$28.54List $36.61
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/4
GradeCP500
MaterialSolid Carbide
CoatingCoated
Description
The Seco 00077959 is a solid carbide indexable insert, grade CP500, Coated coated. Suited for universal.
Specifications
ChipbreakerA2
Coating finishCoated
Coating processPVD
Corner radius0.0030
Cutting edge to theoretical edge length0.0240
Face of insert to tip centerline0.0310
Included angle60
Inscribed circle in1/4
Insert handRight Hand
Insert materialSolid Carbide
Insert style11NR
Manufacturer gradeCP500
Material gradeMicrograin
Msc manufacturer number11NR A60
Pitch (mm)0.50 to 1.50
Primary workpiece materialUniversal
StandardsISO
Thickness0.1181
Threads per inch48-16
Thread typeInternal
