Seco
Indexable Turning & Profiling - Seco 00090974
MFR# 00090974Series Multi-Directional Turning (MDT)
$246.01List $261.36
Save 5%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Seco 00090974 indexable turning & profiling. Suited for universal. Series Multi-Directional Turning (MDT).
Specifications
Back of bar to cutting edge1.2500
Compatible insert size codeLC1605
Complete insert compatibilityLC.. 1605..; LCGN; LCMF; LCMR
Coolant throughNo
Cutting directionLeft Hand
Cutting tool applicationCut-Off; Grooving
Hand of holderLeft Hand
Head length1.4200
Insert compatibilityLC..1605..
Insert holding methodClamp
Insert width0.1870
Lead angle90.0
Maximum depth of cut0.6100
Multi use toolYes
Overall length in6
Primary workpiece materialUniversal
Shank height in1
Shank width in1
Toolholder materialSteel
Toolholder styleCFIL
