SEEX09T3AFN-E04 Solid Carbide Insert, Grade H15 - Seco 02409194

Seco

SEEX09T3AFN-E04 Solid Carbide Insert, Grade H15 - Seco 02409194

MFR# 02409194ISO/ANSI# SEEX09T3AFN-E04Cat# SEEX09T3AFN-E04Series SEEX-09

$18.02List $23.12 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC3/8
ShapeSquare
GradeH15
MaterialSolid Carbide

Description

The Seco 02409194 is a SEEX09T3AFN-E04 solid carbide indexable insert, grade H15. Suited for non-ferrous metal.

Specifications

Ansi codeSEEX09T3AFN-E04
Chip breakerE04
Coating processUncoated
Corner radius0.0118
Cutter series compatibilityR217.53-09; R220.53-09
Cutting edge effective length0.3748
Cutting edge styleSharp
Hole diameter0.1378
Included angle degree90
Inscribed circle in3/8
Inscribed circle range0.3500 to 0.4000
Insert handNeutral
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeSquare
Insert size09
Insert size code09T3
Insert styleSEEX
Iso codeSEEX09T3AFN-E04
Length in3/8
Length range0.3200 to 0.4000
Manufacturers catalog numberSEEX09T3AFN-E04
Manufacturer gradeH15
Material applicationNon-Ferrous Metal
Material gradeMicrograin
Maximum depth of cut0.2795
Multi use toolYes
Number of cutting edges4
Primary workpiece materialNon-Ferrous Metal
RakePositive
Rake angle25
Relief angle20
ShapeSquare
Single or double sided insertSingle
StandardsISO
Thickness in5/32
Thickness range0.1500 to 0.1750
Width in3/8
