Seco
LCEX080402-0310R-N45 Carbide Insert, Grade CP500, TiAlN - Seco 02410926
MFR# 02410926ISO/ANSI# LCEX080402-0310R-N45Series LCE
$32.76List $42.02
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
GradeCP500
MaterialCarbide
CoatingTiAlN
Description
The Seco 02410926 is a LCEX080402-0310R-N45 carbide indexable insert, grade CP500, TiAlN coated. Suited for universal.
Specifications
Chip breakerX
Coating finishTiAlN
Coating processPVD
Insert handRight Hand
Insert holding methodScrew
Insert materialCarbide
Insert size code8
Insert styleLCEX
Iso codeLCEX080402-0310R-N45
Manufacturers catalog number02410926
Manufacturer gradeCP500
Material gradeMicrograin
Number of cutting edges1
Primary workpiece materialUniversal
Rake angle0
Relief angle15
StandardsANSI; ISO
