RCGS6.35-46 Carbide Insert, Grade TS2000, TiAlN - Seco 02616018

Seco

RCGS6.35-46 Carbide Insert, Grade TS2000, TiAlN - Seco 02616018

MFR# 02616018ISO/ANSI# RCGS6.35-46Series T-Lock

$32.33List $41.47 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC1/4
GradeTS2000
MaterialCarbide
CoatingTiAlN

Description

The Seco 02616018 is a RCGS6.35-46 carbide indexable insert, grade TS2000, TiAlN coated. Suited for stainless steel, superalloys & titanium, hard material.

Specifications

ApplicationsProfiling; Turning
Chipbreaker46
Coating finishTiAlN
Coating processPVD
Corner radius0.1250
Hole diameter0.0000
Included angle360
Inscribed circle in1/4
Insert handNeutral
Insert height0.3594
Insert holding methodClamp; Pin
Insert length in1/4
Insert materialCarbide
Insert size code2
Insert styleRCGS
Iso codeRCGS6.35-46
Manufacturer gradeTS2000
Material gradeM01; M10; S01; S10; S20; H30; H40
Maximum depth of cut0.1250
Msc manufacturer numberRCGS2-46
Number of cutting edges4
Primary workpiece materialStainless Steel; Superalloys & Titanium; Hard Material
RakePositive
Relief angle7
ShapeRound
Side length0.2500
StandardsRCGS2-46; RCGS6.35-46
Thickness in23/64
Width in1/4
