RCGS9.525-46 Carbide Insert, Grade TS2000, TiAlN - Seco 02616020

Seco

RCGS9.525-46 Carbide Insert, Grade TS2000, TiAlN - Seco 02616020

MFR# 02616020ISO/ANSI# RCGS9.525-46Series T-Lock

$45.73List $58.65 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC3/8
GradeTS2000
MaterialCarbide
CoatingTiAlN

Description

The Seco 02616020 is a RCGS9.525-46 carbide indexable insert, grade TS2000, TiAlN coated. Suited for stainless steel, superalloys & titanium, hard material.

Specifications

ApplicationsProfiling; Turning
Chipbreaker46
Coating finishTiAlN
Coating processPVD
Corner radius0.1875
Hole diameter0.0000
Included angle360
Inscribed circle in3/8
Insert handNeutral
Insert height0.5157
Insert holding methodClamp; Pin
Insert length in3/8
Insert materialCarbide
Insert size code3
Insert styleRCGS
Iso codeRCGS9.525-46
Manufacturer gradeTS2000
Material gradeM01; M10; S01; S10; S20; H30; H40
Maximum depth of cut0.1875
Msc manufacturer numberRCGS3-46
Number of cutting edges4
Primary workpiece materialStainless Steel; Superalloys & Titanium; Hard Material
RakePositive
Relief angle7
Secondary workpiece materialCast Iron; Hard Material; Steel
ShapeRound
Side length0.3750
StandardsRCGS3-46; RCGS9.525-46
Thickness in33/64
Width in3/8
