RCGS12.7-46 Carbide Insert, Grade TS2500, TiAlN - Seco 02868542

Seco

RCGS12.7-46 Carbide Insert, Grade TS2500, TiAlN - Seco 02868542

MFR# 02868542ISO/ANSI# RCGS4-46Series RCGS-46

$53.64List $68.80 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC1/2
ShapeRound
GradeTS2500
MaterialCarbide
CoatingTiAlN

Description

The Seco 02868542 is a RCGS12.7-46 carbide indexable insert, grade TS2500, TiAlN coated. Suited for superalloys & titanium.

Specifications

Chip breaker46
Clearance codeC
Coating finishTiAlN
Coating processPVD
Corner radius in1/4
Cutting edge styleHoned
Full radiusYes
Included angle360
Industry standard numberRCGS4-46
Inscribed circle in1/2
Insert handNeutral
Insert holding methodWedge
Insert length in1/2
Insert materialCarbide
Insert shapeRound
Insert size code4
Insert styleRCGS
Insert thickness in21/32
Iso codeRCGS12.7-46
Lead angle360
Length range0.5000 - 0.6000
Manufacturers catalog number02868542
Manufacturer gradeTS2500
Material gradeS10; S20
Maximum depth of cut0.2500
Multi use applicationFacing; Profiling; Turning
Multi use toolYes
Number of cutting edges1
Primary workpiece materialSuperalloys & Titanium
RakePositive
Relief angle7
Secondary workpiece materialSteel; Stainless Steel; Cast Iron
StandardsANSI; ISO
Tolerance codeG
Width in1/2
Wiper edgeNo
