Seco
CCMT120404-F1 Carbide Insert, Grade TP2501, TiCN - Seco 02960848
MFR# 02960848ISO/ANSI# CCMT431-F1Series CCMT-F1
$21.12List $27.09
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeDiamond 80
GradeTP2501
MaterialCarbide
CoatingTiCN
Description
The Seco 02960848 is a CCMT120404-F1 carbide indexable insert, grade TP2501, TiCN coated. Suited for steel.
Specifications
Chip breakerF1
Clearance codeC
Coating finishTiCN
Coating processCVD
Corner radius in1/64
Cutting edge styleSharp
Full radiusNo
Hole diameter0.2205
Included angle80degree
Industry standard numberCCMT431-F1
Inscribed circle in1/2
Insert handNeutral
Insert holding methodScrew
Insert length0.5079
Insert materialCarbide
Insert shapeDiamond 80
Insert size code431
Insert styleCCMT
Insert thickness in3/16
Iso codeCCMT120404-F1
Lead angle80degree
Length range0.5000 - 0.6000
Manufacturers catalog number02960848
Manufacturer gradeTP2501
Material gradeP10; P20; P30; P35
Maximum depth of cut0.4921
Multi use applicationBoring; Facing; Turning
Multi use toolYes
Number of cutting edges2
Primary workpiece materialSteel
RakePositive
Relief angle7
Secondary workpiece materialStainless Steel; Cast Iron
Single or multi tippedMulti Tipped
StandardsANSI; ISO
Tolerance codeM
Width in1/2in
Wiper edgeNo
