Seco
Solid Carbide Insert, Grade TGH1050, TiAlSiN - Seco 02968212
MFR# 02968212Series X4
$78.16List $100.24
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
GradeTGH1050
MaterialSolid Carbide
CoatingTiAlSiN
Description
The Seco 02968212 is a solid carbide indexable insert, grade TGH1050, TiAlSiN coated. Suited for universal.
Specifications
Chip breakerFG
Coating finishTiAlSiN
Coating processPVD
Corner radius (mm)0.05
Cutting height0.8030
Cutting width0.0200
Full radiusNo
Insert handLeft Hand
Insert materialSolid Carbide
Insert size2503005
Insert size code25030050050
Insert styleX4GKL
Lead angle0
Manufacturer gradeTGH1050
Maximum corner radius0.0031
Maximum depth of cut0.1020
Maximum depth of cut range0.1000 to 0.1500
Minimum corner radius0.0008
Multi use toolYes
Overall length1.0010
Primary workpiece materialUniversal
RakePositive
Rake angle6.00
Single or double endDouble
StandardsISO
