Seco
Solid Carbide Insert, Grade TGH1050, TiAlSiN - Seco 02968215
MFR# 02968215Series X4
$70.74List $90.72
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
GradeTGH1050
MaterialSolid Carbide
CoatingTiAlSiN
Description
The Seco 02968215 is a solid carbide indexable insert, grade TGH1050, TiAlSiN coated. Suited for universal.
Specifications
Chip breakerFG
Coating finishTiAlSiN
Coating processPVD
Corner radius (mm)0.10
Cutting height0.8030
Cutting width0.0600
Full radiusNo
Insert handRight Hand
Insert materialSolid Carbide
Insert size2503010
Insert size code25030100150
Insert styleX4GKR
Lead angle0
Manufacturer gradeTGH1050
Maximum corner radius0.0051
Maximum depth of cut0.2560
Maximum depth of cut range0.2000 to 0.3000
Minimum corner radius0.0028
Multi use toolYes
Overall length1.0010
Primary workpiece materialUniversal
RakePositive
Rake angle6.00
Single or double endDouble
StandardsISO
