Seco

3/8" 4-Flute Solid Carbide Ball End Mill, AlTiN - Seco 03083829

MFR# 03083829Cat# STB440.2-0.375-D2-B.3-Z4Series STB440.2

$76.91List $98.64 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter3/8

Flutes4

MaterialSolid Carbide

CoatingAlTiN

Description

The Seco 03083829 is a 3/8 4-flute Solid Carbide (Micrograin) ball end mill with a AlTiN finish for longer tool life. Suited for stainless steel, superalloys & titanium, hard material. 3/4 length of cut, 2-1/2 overall length. Series STB440.2.

Specifications

ChipbreakerNo

Coating finishAlTiN

Coolant throughNo

Cutting directionRight Hand

End mill materialSolid Carbide

Extended reachNo

Flute directionRight Hand

Flute typeSpiral

Helix styleVariable

Length of cut in3/4

Length typeShort

Manufacturers catalog numberSTB440.2-0.375-D2-B.3-Z4

Material gradeMicrograin

Material removal typeRoughing & Finishing

Mill diameter in3/8

Mill diameter tolerance+0.0000/-0.0020 in

Neck length0.0000

Nose radius0.1875

Number of flutes4

Overall length in2-1/2

Overall length tolerance+0.0600/-0.0600 in

Primary workpiece materialStainless Steel; Superalloys & Titanium; Hard Material

Reach length0.7500

Shank diameter in3/8

Shank diameter tolerance-0.0001/-0.0004 in

Shank typeWeldon Flat

Single or double endSingle

System of measurementFractional Inch

Tir maximum0.0005

Variable helixYes

Variable indexNo
