3/8" 4-Flute Solid Carbide Corner Radius End Mill, AlTiN - Seco 03084151

Seco

3/8" 4-Flute Solid Carbide Corner Radius End Mill, AlTiN - Seco 03084151

MFR# 03084151Series STR440.2

$56.66List $72.66 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter3/8
Flutes4
MaterialSolid Carbide
CoatingAlTiN

Description

The Seco 03084151 is a 3/8 4-flute Solid Carbide (Micrograin) corner radius end mill with a AlTiN finish for longer tool life. Suited for stainless steel, superalloys & titanium, hard material. 3/8 length of cut, 2 overall length. Series STR440.2.

Specifications

CentercuttingYes
ChipbreakerNo
Coating finishAlTiN
Coolant throughNo
Corner radius0.0200
Corner radius tolerance0.00100 in; +0.02500 to -0.02500 mm
Cutting directionRight Hand
End mill materialSolid Carbide
End typeCorner Radius
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
For use withToolholders
Helix styleHigh
Length of cut in3/8
Length typeStub
Material applicationStainless Steel; Superalloys & Titanium; Hard Material
Material gradeMicrograin
Material removal typeRoughing & Finishing
Mill diameter in3/8
Mill diameter tolerance-0.0020/0.0000 in
Number of flutes4
Overall length in2
Overall length tolerance-0.0600/0.0600 in
PitchNormal
Primary workpiece materialStainless Steel; Superalloys & Titanium; Hard Material
Shank diameter in3/8
Shank diameter tolerance-0.0001/-0.0004 in
Shank typeStraight-Cylindrical
Single or double endSingle
Tir maximum0.0005
Variable helixYes
Variable indexNo
