CCGW09T308S-02020-L1-B PCBN Insert, Grade CH3515, TiAlN - Seco 03120429

Seco

CCGW09T308S-02020-L1-B PCBN Insert, Grade CH3515, TiAlN - Seco 03120429

MFR# 03120429ISO/ANSI# CCGW09T308Series CCGW-Flat Top

$99.73
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC3/8
ShapeC - Diamond (Rhombic) 80-Deg
GradeCH3515
MaterialPCBN
CoatingTiAlN

Description

The Seco 03120429 is a CCGW09T308S-02020-L1-B pcbn indexable insert, grade CH3515, TiAlN coated. Suited for cast iron, hard material.

Specifications

Ansi insert codeCCGW32.52
Ansi size code32.52
Chip breakerFlat Top
Chip breaker operationFlat Top
Clearance codeC
Coating finishTiAlN
Coating processPCBN
Corner radius in1/32
Cutting edge styleChamfered; Honed
Full radiusNo
Grade characteristicsCast Iron (K) - High Wear-Resistance to High Toughness
Hole diameter0.1772
Included angle80
Industry standard numberCCGW32.52S-00820-L1-B
Inscribed circle in3/8
Insert handNeutral
Insert holding methodScrew
Insert length0.3819
Insert materialPCBN
Insert shapeC - Diamond (Rhombic) 80-Deg
Insert size code32.52
Insert styleCCGW
Insert thickness in5/32
Iso codeCCGW09T308S-02020-L1-B
Iso insert codeCCGW09T308
Iso size code09T308
Lead angle80
Length range0.3000 - 0.4000
Manufacturers catalog number03120429
Manufacturer gradeCH3515
Material gradeK10; K20; K30; H30; H40
Maximum depth of cut0.0400
Multi use applicationBoring; Facing; Turning
Multi use toolYes
Number of cutting edges2
Primary workpiece materialCast Iron; Hard Material
RakePositive
Rake angle0
Relief angle7
Side clearancePositive
Single or multi tippedMulti Tipped
StandardsANSI; ISO
Tip length0.0940
Tolerance codeG
Width in3/8
Wiper edgeNo
