CNMG120404-MF1 Carbide Insert, Grade TM2501, TiCN - Seco 03275987

Seco

CNMG120404-MF1 Carbide Insert, Grade TM2501, TiCN - Seco 03275987

MFR# 03275987ISO/ANSI# CNMP120404Series CNMP-MF1

$19.12List $24.52 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC1/2
ShapeC - Diamond (Rhombic) 80-Deg
GradeTM2501
MaterialCarbide
CoatingTiCN

Description

The Seco 03275987 is a CNMG120404-MF1 carbide indexable insert, grade TM2501, TiCN coated. Suited for stainless steel.

Specifications

Ansi insert codeCNMP431
Ansi size code431
Chip breakerMF1
Chip breaker operationFinishing
Clearance codeN
Coating finishTiCN
Coating processCVD
Corner radius in1/64
Cutting edge styleHoned
Full radiusNo
Grade characteristicsSteel (P) - High Toughness; Stainless Steel (M) - Moderate Wear-Resistance and Toughness to High Toughness
Hole diameter0.2028
Included angle80
Industry standard numberCNMP431-MF1
Inscribed circle in1/2
Insert handNeutral
Insert holding methodClamp; Pin; Lever Lock
Insert length0.5079
Insert materialCarbide
Insert shapeC - Diamond (Rhombic) 80-Deg
Insert size code431
Insert styleCNMP
Insert thickness in3/16
Iso codeCNMG120404-MF1
Iso insert codeCNMP120404
Iso size code120404
Lead angle80
Length range0.5000 - 0.6000
Manufacturers catalog number03275987
Manufacturer gradeTM2501
Material gradeM25; M30; M35
Maximum depth of cut0.4917
Multi use applicationBoring; Facing; Turning
Multi use toolYes
Number of cutting edges4
Primary workpiece materialStainless Steel
RakeNegative
Rake angle18
Relief angle0
Secondary workpiece materialSteel
Side clearanceNegative
StandardsANSI; ISO
Tolerance codeM
Width in1/2
Wiper edgeNo
