RPHT1605M0T-8-M12 Solid Carbide Insert, Grade MS2050, TiAlN - Seco 03280051
MFR# 03280051ISO/ANSI# RPHT1605M0T-8-M12Cat# RPHT1605M0T-8-M12Series RPHT-16
$26.19List $33.59
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
ShapeRound
GradeMS2050
MaterialSolid Carbide
CoatingTiAlN
Description
The Seco 03280051 is a RPHT1605M0T-8-M12 solid carbide indexable insert, grade MS2050, TiAlN coated. Suited for superalloys & titanium.
Specifications
Ansi codeRPHT1605M0T-8-M12
Chip breakerM12
Coating finishTiAlN
Coating processPVD
Corner radius0.3150
Cutter series compatibilityR217.29-08; R220.29-08
Cutting edge effective length0.3150
Cutting edge styleT-Land
Hole diameter0.2205
Included angle degree360
Inscribed circle0.6299
Inscribed circle range0.6000 to 0.7000
Insert handNeutral
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeRound
Insert size16
Insert size code1605
Insert styleRPHT
Iso codeRPHT1605M0T-8-M12
Length0.6299
Length range0.6000 to 0.6500
Manufacturers catalog numberRPHT1605M0T-8-M12
Manufacturer gradeMS2050
Material applicationSteel; Stainless Steel; Superalloys & Titanium
Material gradeMicrograin
Maximum depth of cut0.3150
Multi use toolYes
Number of cutting edges8
Primary workpiece materialSuperalloys & Titanium
RakePositive
Rake angle15
Relief angle11.00
Secondary workpiece materialSteel; Stainless Steel
ShapeRound
Single or double sided insertSingle
StandardsISO
Thickness in7/32
Thickness range0.2000 to 0.2200
Width0.6299
