Seco
1/8" 3-Flute Solid Carbide Corner Radius End Mill, AlTiN - Seco 17003401
MFR# 17003401Series Elite S
$46.18List $58.20
Save 20%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
Supplier prices are confirmed before checkout. If one has changed since this page was updated, we show you the new price before you pay.
Request a quote- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Diameter1/8
Flutes3
MaterialSolid Carbide
CoatingAlTiN
Description
The Seco 17003401 is a 1/8 3-flute Solid Carbide corner radius end mill with a AlTiN finish for longer tool life. Suited for steel, stainless steel, superalloys & titanium. 1/2 length of cut, 1-1/2 overall length. Series Elite S.
Specifications
CentercuttingYes
ChipbreakerNo
Coating finishAlTiN
Coolant throughNo
Corner radius0.0100
Corner radius tolerance+0.00100 to -0.00100 in
Cutting directionRight Hand
End mill materialSolid Carbide
End typeCorner Radius
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
For use withToolholders
Helix styleMedium
Length of cut in1/2
Length typeLong
Material applicationSteel; Stainless Steel; Superalloys & Titanium
Material removal typeRoughing & Finishing
Mill diameter in1/8
Mill diameter tolerance0.00/- 0.002
Number of flutes3
Overall length in1-1/2
Overall length tolerance+to- 0.060
PitchCoarse
Primary workpiece materialSteel; Stainless Steel; Superalloys & Titanium
Shank diameter in1/8
Shank diameter tolerance- 0.0001/- 0.0004
Shank typeStraight-Cylindrical
Single or double endSingle
Variable helixNo
Variable indexNo
