Seco
7/32" 3-Flute Solid Carbide Corner Radius End Mill, AlTiN - Seco 17003406
MFR# 17003406Series S335
$52.69List $66.40
Save 20%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
Supplier prices are confirmed before checkout. If one has changed since this page was updated, we show you the new price before you pay.
Request a quote- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Diameter7/32
Flutes3
MaterialSolid Carbide
CoatingAlTiN
Description
The Seco 17003406 is a 7/32 3-flute Solid Carbide corner radius end mill with a AlTiN finish for longer tool life. Suited for steel, stainless steel, superalloys & titanium. 3/8 length of cut, 2 overall length. Series S335.
Specifications
CentercuttingYes
ChipbreakerNo
Coating finishAlTiN
Coolant throughNo
Corner radius0.0200
Corner radius tolerance+0.00100 to -0.00100 in
Cutting directionRight Hand
End mill materialSolid Carbide
End typeCorner Radius
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
For use withToolholders
Helix styleMedium
Length of cut in3/8
Length typeShort
Material applicationSteel; Stainless Steel; Superalloys & Titanium
Material removal typeRoughing & Finishing
Mill diameter in7/32
Mill diameter tolerance-0.0020/0.0000 in
Number of flutes3
Overall length in2
Overall length tolerance-0.0600/0.0600 in
PitchCoarse
Primary workpiece materialSteel; Stainless Steel; Superalloys & Titanium
Shank diameter in1/4
Shank diameter tolerance-0.0001/-0.0004 in
Shank typeStraight-Cylindrical
Single or double endSingle
Tir maximum0.0005
Variable helixNo
Variable indexNo
