0.375" 3-Flute Solid Carbide Roughing End Mill, TiCN - Seco 17004715

Seco

0.375" 3-Flute Solid Carbide Roughing End Mill, TiCN - Seco 17004715

MFR# 17004715Series AR330

$103.70List $133.00 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Flutes3
MaterialSolid Carbide
CoatingTiCN

Description

The Seco 17004715 is a 0.375 3-flute Solid Carbide (M42) roughing end mill with a TiCN finish for longer tool life. Series AR330.

Specifications

CentercuttingYes
Chamfer angle45
Chamfer width0.0200
Coating finishTiCN
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
Length of cut1.0000
Length typeRegular
Material gradeM42
Maximum helix angle30
Mill diameter0.375
Mill diameter frac in3/8
Mill diameter tolerance+0.000 to -0.003 in
Number of flutes3
Overall length tolerance+0.060 to -0.060 in
PitchCoarse
Shank diameter in3/8
Shank diameter tolerance-0.0001 to -0.0004 in
Shank typeStraight-Cylindrical
Single or double endSingle
