1/64" 4-Flute Solid Carbide Ball End Mill, CVD Diamond - Seco 17004995

MFR# 17004995Cat# DIAB430-0.016-F3-B.0-Z4Series DIAB430

$174.31List $223.57 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter1/64

Flutes4

MaterialSolid Carbide

CoatingCVD Diamond

Description

The Seco 17004995 is a 1/64 4-flute Solid Carbide ball end mill with a CVD Diamond finish for longer tool life. 3/64 length of cut, 1-1/2 overall length. Series DIAB430.

Specifications

ChipbreakerNo

Coating finishCVD Diamond

Coolant throughNo

Cutting directionRight Hand

End mill materialSolid Carbide

Extended reachNo

Flute directionRight Hand

Flute typeSpiral

Helix angle30

Helix styleMedium

Length of cut in3/64

Length typeStandard

Manufacturers catalog numberDIAB430-0.016-F3-B.0-Z4

Material removal typeRoughing & Finishing

Mill diameter in1/64

Mill diameter tolerance+0.0000/-0.0020 in

Neck diameter0.0156

Neck length0.0000

Nose radius0.0078

Number of flutes4

Overall length in1-1/2

Overall length tolerance+0.0600/-0.0600 in

Reach length in3/64

Shank diameter in1/8

Shank diameter tolerance-0.0001/-0.0004 in

Shank typeStraight-Cylindrical

Single or double endSingle

System of measurementFractional Inch

Tir maximum0.0001

Variable helixNo

Variable indexNo
