RCGS6.35-46 Carbide Insert, Grade 883 - Seco 74043731
MFR# 74043731ISO/ANSI# RCGS6.35-46Series T-Lock
$25.42List $32.61
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/4
Grade883
MaterialCarbide
Description
The Seco 74043731 is a RCGS6.35-46 carbide indexable insert, grade 883. Suited for non-ferrous metal, superalloys & titanium, hard material.
Specifications
ApplicationsProfiling; Turning
Chipbreaker46
Coating processUncoated
Corner radius0.1250
Hole diameter0.0000
Included angle360
Inscribed circle in1/4
Insert handNeutral
Insert height0.3594
Insert holding methodClamp; Pin
Insert length in1/4
Insert materialCarbide
Insert size code2F
Insert styleRCGS
Iso codeRCGS6.35-46
Manufacturer grade883
Material gradeN10; N20; N30; S10; S20; S30; H30; H40
Maximum depth of cut0.1250
Msc manufacturer numberRCGS2F-46
Number of cutting edges4
Primary workpiece materialNon-Ferrous Metal; Superalloys & Titanium; Hard Material
RakePositive
Relief angle7
Secondary workpiece materialUniversal
ShapeRound
Side length0.2500
StandardsRCGS2F-46; RCGS6.35-46
Thickness in23/64
Width in1/4
