1" 2-Flute Solid Carbide Square End Mill - SGS 34531
MFR# 34531Series 44
$717.62List $920.37
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Diameter1
Flutes2
MaterialSolid Carbide
Description
The SGS 34531 is a 1 2-flute Solid Carbide square end mill. Suited for non-ferrous metal. 2 length of cut, 4-1/2 overall length. Series 44.
Specifications
CentercuttingYes
ChipbreakerNo
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
Helix angle45
Length of cut in2
Length typeStub
Mill diameter in1
Mill diameter tolerance+0.00000/-0.00051 in
Number of flutes2
Overall length in4-1/2
Primary workpiece materialNon-Ferrous Metal
Shank diameter in1
Shank diameter tolerance+0.00000/-0.00051 in
Shank typeWeldon Flat
Variable helixNo
Variable indexNo
