SGS
1" 6-Flute Solid Carbide Square End Mill, TiN - SGS 35105
MFR# 35105Series 51
$649.78List $833.38
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Diameter1
Flutes6
MaterialSolid Carbide
CoatingTiN
Description
The SGS 35105 is a 1 6-flute Solid Carbide square end mill with a TiN finish for longer tool life. 2-5/8 length of cut, 6 overall length. Series 51.
Specifications
CentercuttingYes
ChipbreakerNo
Coating finishTiN
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
Helix angle41
Length of cut in2-5/8
Length of cut range2.0000+
Length typeRegular
Mill diameter in1
Mill diameter tolerance+0.000/-0.002 in
Number of flutes6
Overall length in6
Shank diameter in1
Shank diameter tolerance+0.00000/-0.00051 in
Shank typeStraight-Cylindrical
Variable helixNo
Variable indexYes
