1/4" 6-Flute Solid Carbide Square End Mill, TiN - SGS 35106

MFR# 35106Series 51L

$54.06List $69.34 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter1/4

Flutes6

MaterialSolid Carbide

CoatingTiN

Description

The SGS 35106 is a 1/4 6-flute Solid Carbide (Micrograin) square end mill with a Titanium Nitride finish for longer tool life. 3/8 length of cut, 4 overall length. Series 51L.

Specifications

CentercuttingYes

ChipbreakerNo

Coating finishTiN

Cutting directionRight Hand

End mill materialSolid Carbide

Extended reachYes

Flute directionRight Hand

Flute typeSpiral

Helix angle41

Length of cut in3/8

Length of cut range0.3000 - 0.5000

Length typeLong

Material gradeMicrograin

Mill diameter in1/4

Mill diameter tolerance+0.000/-0.002 in

Number of flutes6

Overall length in4

Reach length in1-1/8

Shank diameter in1/4

Shank diameter tolerance+0.00000/-0.00035 in

Shank typeStraight-Cylindrical

Variable helixNo

Variable indexYes
