5/8" 6-Flute Solid Carbide Square End Mill, TiN - SGS 35109

MFR# 35109Series 51L

$281.86List $361.49 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter5/8

Flutes6

MaterialSolid Carbide

CoatingTiN

Description

The SGS 35109 is a 5/8 6-flute Solid Carbide (Micrograin) square end mill with a Titanium Nitride finish for longer tool life. 3/4 length of cut, 5 overall length. Series 51L.

Specifications

CentercuttingYes

ChipbreakerNo

Coating finishTiN

Cutting directionRight Hand

End mill materialSolid Carbide

Extended reachYes

Flute directionRight Hand

Flute typeSpiral

Helix angle41

Length of cut in3/4

Length of cut range0.7000 - 0.8000

Length typeLong

Material gradeMicrograin

Mill diameter in5/8

Mill diameter tolerance+0.000/-0.002 in

Number of flutes6

Overall length in5

Reach length in2-1/2

Shank diameter in5/8

Shank diameter tolerance+0.00000/-0.00043 in

Shank typeStraight-Cylindrical

Variable helixNo

Variable indexYes
