SGS

3/8" 2-Flute Solid Carbide Corner Radius End Mill, TiN - SGS 38248

MFR# 38248Series 03C

$56.58List $72.56 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter3/8

Flutes2

MaterialSolid Carbide

CoatingTiN

Description

The SGS 38248 is a 3/8 2-flute Solid Carbide (Micrograin) corner radius end mill with a TiN finish for longer tool life. Suited for steel, stainless steel, cast iron, non-ferrous metal, superalloys & titanium. 1 length of cut, 2-1/2 overall length. Series 03C.

Specifications

CentercuttingNo

ChipbreakerNo

Coating finishTiN

Coolant throughNo

Corner radius0.0200

Corner radius tolerance-0.0020 to 0.0000 in

Cutting directionRight Hand

End mill materialSolid Carbide

End typeCorner Radius

Extended reachNo

Flute directionRight Hand

Flute typeHelical

For use withEnd Mill Holders

Helix styleMedium

Length of cut in1

Length typeStandard

Material applicationSteel; Stainless Steel; Cast Iron; Non-Ferrous Metal; Superalloys & Titanium; Hard Material

Material gradeMicrograin

Material removal typeRoughing

Mill diameter in3/8

Mill diameter tolerance-0.0020 to -0.0010 in

Number of flutes2

Overall length in2-1/2

PitchCoarse

Primary workpiece materialSteel; Stainless Steel; Cast Iron; Non-Ferrous Metal; Superalloys & Titanium

Secondary workpiece materialHard Material

Shank diameter in3/8

Shank diameter toleranceh6

Shank typeWeldon Flat

Single or double endSingle

Variable helixNo

Variable indexNo
