5/32" 3-Flute Solid Carbide Square End Mill, TiN - SGS 39719

MFR# 39719Series 5

$22.32List $28.62 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter5/32

Flutes3

MaterialSolid Carbide

CoatingTiN

Description

The SGS 39719 is a 5/32 3-flute Solid Carbide (Micrograin) square end mill with a Titanium Nitride finish for longer tool life. 1/2 length of cut, 2 overall length. Series 5.

Specifications

CentercuttingYes

ChipbreakerNo

Coating finishTiN

Cutting directionRight Hand

End mill materialSolid Carbide

Extended reachNo

Flute directionRight Hand

Flute typeSpiral

Helix angle30

Length of cut in1/2

Length of cut range0.5000 - 0.6000

Length typeRegular

Material gradeMicrograin

Mill diameter in5/32

Mill diameter tolerance+0.000/-0.002 in

Number of flutes3

Overall length in2

Shank diameter in3/16

Shank diameter tolerance+0.00000/-0.00032 in

Shank typeStraight-Cylindrical

Variable helixNo

Variable indexNo
