Sumitomo
Square 1/2" IC Solid Carbide Insert, Grade ACP200, Coated - Sumitomo 14HA897
MFR# 14HA897
$13.16List $16.89
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeSquare
GradeACP200
MaterialSolid Carbide
CoatingCoated
Description
The Sumitomo 14HA897 is a solid carbide indexable insert, grade ACP200, Coated coated. Suited for stainless steel, steel.
Specifications
Chip breakerG
Coating finishCoated
Coating processPVD
Cutter series compatibilityWGX
Cutting edge effective length0.5280
Inscribed circle in1/2
Inscribed circle range0.5000 to 0.5100
Insert materialSolid Carbide
Insert shapeSquare
Insert size13T3
Insert size code13
Insert styleSEMT
Manufacturer gradeACP200
Primary workpiece materialStainless Steel; Steel
Relief angle20
Thickness0.1560
Thickness range0.1500 to 0.1750
Width0.5280
