Sumitomo
Square 1/2" IC Solid Carbide Insert, Grade ACP200 - Sumitomo 14HA980
MFR# 14HA980
$15.51List $19.90
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeSquare
GradeACP200
MaterialSolid Carbide
Description
The Sumitomo 14HA980 is a solid carbide indexable insert, grade ACP200. Suited for stainless steel, steel.
Specifications
Chip breakerG
Coating processPVD
Cutter series compatibilityWGX
Cutting edge effective length (mm)13.40
Inscribed circle in1/2
Inscribed circle range0.5000 to 0.5100
Insert materialSolid Carbide
Insert shapeSquare
Insert size13T3
Insert size code13
Insert styleSEET
Manufacturer gradeACP200
Primary workpiece materialStainless Steel; Steel
Relief angle20.00
Thickness0.1900
Thickness range0.1850 to 0.2000
