Sumitomo
WNMG080408N-SX Cermet Insert, Grade T1500Z, Coated - Sumitomo 194ABFA
MFR# 194ABFAISO/ANSI# WNMG080402Series WN
$9.94List $12.76
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeW - Trigon 80-Deg
GradeT1500Z
MaterialCermet
CoatingCoated
Description
The Sumitomo 194ABFA is a WNMG080408N-SX cermet indexable insert, grade T1500Z, Coated coated. Suited for steel.
Specifications
Ansi insert codeWNMG432
Ansi size code432
Chip breakerESX
Chip breaker operationFinishing; Light Machining
Clearance codeN
Coating finishCoated
Coating processPVD
Corner radius in1/32
Grade characteristicsSteel (P) - High Wear-Resistance to Moderate Wear-Resistance and Toughness
Hole diameter0.2031
Included angle80
Inscribed circle in1/2
Insert handNeutral
Insert holding methodClamp; Pin
Insert length0.3425
Insert materialCermet
Insert shapeW - Trigon 80-Deg
Insert size code432
Insert styleWNMG
Insert thickness in3/16
Iso codeWNMG080408N-SX
Iso insert codeWNMG080402
Iso size code080402
Manufacturer gradeT1500Z
Primary workpiece materialSteel
RakeNegative
Relief angle0
Side clearanceNegative
StandardsANSI; ISO 13399
Tolerance codeM
