Sumitomo
VNMG160408N-LU Cermet Insert, Grade T1500Z, Coated - Sumitomo 194ABUJ
MFR# 194ABUJISO/ANSI# VNMG160408N-LUSeries VN
$17.85List $22.49
Save 20%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
⚡ Need it urgently? Confirm stock & ship time →
Sold in multiples of 10 — minimum order 10
Request a quote- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC3/8
ShapeDiamond
GradeT1500Z
MaterialCermet
CoatingCoated
Description
The Sumitomo 194ABUJ is a VNMG160408N-LU cermet indexable insert, grade T1500Z, Coated coated. Suited for steel.
Specifications
Ansi codeVNMG332ELU
Chip breakerELU
Clearance codeN
Coating finishCoated
Coating processPVD
Corner radius in1/32
Hole diameter0.1500
Included angle35.0
Inscribed circle in3/8
Insert handNeutral
Insert holding methodClamp; Pin
Insert length0.6535
Insert materialCermet
Insert shapeDiamond
Insert size code332
Insert styleVNMG
Insert thickness in3/16
Iso codeVNMG160408N-LU
Manufacturer gradeT1500Z
Primary workpiece materialSteel
RakeNegative
Relief angle0
StandardsANSI; ISO 13399
Tolerance codeM
