CNMG120408N-MU Carbide Insert, Grade YB100, Al2O3 - Sumitomo 19QKAFI

Sumitomo

CNMG120408N-MU Carbide Insert, Grade YB100, Al2O3 - Sumitomo 19QKAFI

MFR# 19QKAFIISO/ANSI# CNMG120408Series CN

$12.31List $15.78 Save 21%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC1/2
ShapeC - Diamond (Rhombic) 80-Deg
GradeYB100
MaterialCarbide
CoatingAl2O3

Description

The Sumitomo 19QKAFI is a CNMG120408N-MU carbide indexable insert, grade YB100, Al2O3 coated.

Specifications

Ansi insert codeCNMG432
Ansi size code432
Chip breakerEMU
Chip breaker operationLight Machining; Medium Machining
Clearance codeN
Coating finishAl2O3
Coating processCVD
Corner radius in1/32
Grade characteristicsSteel (P) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Cast Iron (K) - High Wear-Resistance to Moderate Wear-Resistance and Toughness
Hole diameter0.2031
Included angle80
Inscribed circle in1/2
Insert handNeutral
Insert holding methodClamp; Pin
Insert length0.5079
Insert materialCarbide
Insert shapeC - Diamond (Rhombic) 80-Deg
Insert size code432
Insert styleCNMG
Insert thickness in3/16
Iso codeCNMG120408N-MU
Iso insert codeCNMG120408
Iso size code120408
Manufacturer gradeYB100
RakePositive
Rake angle4
Relief angle0
Side clearanceNegative
StandardsANSI; ISO 13399
Tolerance codeM
