Sumitomo
SNMG543 Solid Carbide Insert, Grade AC830P, Absotech - Sumitomo 19RBALJ
MFR# 19RBALJISO/ANSI# SNMG543Series SN
$17.74List $22.75
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC5/8
ShapeSquare
GradeAC830P
MaterialSolid Carbide
CoatingAbsotech
Description
The Sumitomo 19RBALJ is a SNMG543 solid carbide indexable insert, grade AC830P, Absotech coated. Suited for m, p.
Specifications
Ansi codeSNMG543EMU
Chip breakerEMU
Clearance codeN
Coating finishAbsotech
Coating processCVD
Corner radius in3/64
Hole diameter0.2500
Included angle90.0
Inscribed circle in5/8
Insert handNeutral
Insert holding methodClamp; Pin
Insert length in5/8
Insert materialSolid Carbide
Insert shapeSquare
Insert size code543
Insert styleSNMG
Insert thickness in1/4
Iso codeSNMG543
Manufacturer gradeAC830P
Material gradeC5; C5A; C6
Primary workpiece materialM; P
RakeNegative
Relief angle0
Secondary workpiece materialUniversal
StandardsANSI; ISO 13399
Tolerance codeM
Width in5/8
