Sumitomo
DCMT070204N-SK Solid Carbide Insert, Grade AC830P, Coated - Sumitomo 19RBW4V
MFR# 19RBW4VISO/ANSI# DCMT070204N-SKSeries DC
$14.40List $18.46
Save 21%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/4
ShapeDiamond
GradeAC830P
MaterialSolid Carbide
CoatingCoated
Description
The Sumitomo 19RBW4V is a DCMT070204N-SK solid carbide indexable insert, grade AC830P, Coated coated. Suited for m, p.
Specifications
Ansi codeDCMT21.51ENK
Chip breakerENK
Clearance codeC
Coating finishCoated
Coating processCVD
Corner radius in1/64
Hole diameter0.1100
Included angle55.0
Inscribed circle in1/4
Insert handNeutral
Insert holding methodScrew
Insert length0.3031
Insert materialSolid Carbide
Insert shapeDiamond
Insert size code21.51
Insert styleDCMT
Insert thickness in3/32
Iso codeDCMT070204N-SK
Manufacturer gradeAC830P
Material gradeC5; C5A; C6
Primary workpiece materialM; P
RakePositive
Relief angle7
Secondary workpiece materialUniversal
StandardsANSI; ISO 13399
Tolerance codeM
