Sumitomo
TCMT16T308N-SK Solid Carbide Insert, Grade AC830P, Coated - Sumitomo 19RBWA0
MFR# 19RBWA0ISO/ANSI# TCMT16T308N-SKSeries TC
$15.95List $20.10
Save 20%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
⚡ Need it urgently? Confirm stock & ship time →
Sold in multiples of 10 — minimum order 10
Request a quote- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC3/8
ShapeTriangle
GradeAC830P
MaterialSolid Carbide
CoatingCoated
Description
The Sumitomo 19RBWA0 is a TCMT16T308N-SK solid carbide indexable insert, grade AC830P, Coated coated. Suited for m, p.
Specifications
Ansi codeTCMT32.52ENK
Chip breakerENK
Clearance codeC
Coating finishCoated
Coating processCVD
Corner radius in1/32
Hole diameter0.1690
Included angle60.0
Inscribed circle in3/8
Insert handNeutral
Insert holding methodScrew
Insert length0.6496
Insert materialSolid Carbide
Insert shapeTriangle
Insert size code32.52
Insert styleTCMT
Insert thickness in5/32
Iso codeTCMT16T308N-SK
Manufacturer gradeAC830P
Material gradeC5; C5A; C6
Primary workpiece materialM; P
RakePositive
Relief angle7
Secondary workpiece materialUniversal
StandardsANSI; ISO 13399
Tolerance codeM
