Sumitomo
TNMG270616N-MU Solid Carbide Insert, Grade AC820P, Coated - Sumitomo 19RJALG
MFR# 19RJALGISO/ANSI# TNMG270616N-MUSeries TN
$24.59List $31.54
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC5/8
ShapeTriangle
GradeAC820P
MaterialSolid Carbide
CoatingCoated
Description
The Sumitomo 19RJALG is a TNMG270616N-MU solid carbide indexable insert, grade AC820P, Coated coated. Suited for m, p.
Specifications
Ansi codeTNMG544EMU
Chip breakerEMU
Clearance codeN
Coating finishCoated
Coating processCVD
Corner radius in1/16
Hole diameter0.2500
Included angle60.0
Inscribed circle in5/8
Insert handNeutral
Insert holding methodClamp; Pin
Insert length1.0827
Insert materialSolid Carbide
Insert shapeTriangle
Insert size code544
Insert styleTNMG
Insert thickness in1/4
Iso codeTNMG270616N-MU
Manufacturer gradeAC820P
Material gradeC5A; C6; C7; C8
Primary workpiece materialM; P
RakeNegative
Relief angle0
Secondary workpiece materialSteel
StandardsANSI; ISO 13399
Tolerance codeM
