Tungaloy
Carbide Insert, Grade AH9130, TiAlN - Tungaloy 6771177
MFR# 6771177Series DMP
$95.36List $122.30
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes2
GradeAH9130
CoatingTiAlN
Description
The Tungaloy 6771177 is a carbide indexable insert, grade AH9130, TiAlN coated. Suited for steel, stainless steel, cast iron, superalloys & titanium.
Specifications
ApplicationsGeneral Drilling; Holemaking
Coating finishTiAlN
Coating processPVD
Coolant throughNo
Cutting diameter in13/32
Drill point angle140
Flute length (mm)5.00
Flute typeHelical
Functional length0.1785
Height (mm)6.00
Included angle degree140
Insert holding methodClamp
Insert seat size10
Iso numberDMP103
Manufacturer gradeAH9130
Material gradeP15; P35; M25; M35; K10; K25; S15; S30
Number of flutes2
Overall length projection0.2384
Point typeStandard
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Superalloys & Titanium
Spiral typeRegular Spiral
StyleDMP
Tip materialSolid Carbide
