Tungaloy
CNMA432 Ceramic Insert, Grade FX105 - Tungaloy 6801915
MFR# 6801915ISO/ANSI# CNMA 432Series CNM/GA
$14.62List $18.75
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeDiamond 80
GradeFX105
MaterialCeramic
Description
The Tungaloy 6801915 is a CNMA432 ceramic indexable insert, grade FX105. Suited for cast iron.
Specifications
Chip breakerFlat Top
Clearance codeN
Coating processUncoated
Corner radius in1/32
Cutting edge styleHoned
Full radiusNo
Hole diameter0.2030
Included angle80degree
Industry standard numberCNMA 432
Inscribed circle in1/2
Insert handNeutral
Insert holding methodClamp; Pin
Insert length0.5080
Insert materialCeramic
Insert shapeDiamond 80
Insert size code432
Insert styleCNMA
Insert thickness in3/16
Iso codeCNMA432
Length range0.5000 - 0.6000
Manufacturers catalog number6801915
Manufacturer gradeFX105
Material gradeSilicon Nitride
Maximum depth of cut0.1181
Multi use applicationTurning; Facing; Boring
Multi use toolYes
Number of cutting edges4
Primary workpiece materialCast Iron
RakeNegative
Rake angle0
Relief angle0
StandardsANSI; ISO
Tolerance codeM
Width in1/2in
Wiper edgeNo
