DNGA 32H Polycrystalline Cubic Boron Nitride (PCBN) Insert, Grade BXM20, TiCN - Tungaloy 6804794
MFR# 6804794ISO/ANSI# 2QP-DNGA 432-HSeries 2QP-DNGA
$75.57List $84.90
Save 10%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
Supplier prices are confirmed before checkout. If one has changed since this page was updated, we show you the new price before you pay.
Request a quote- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeDiamond 55
GradeBXM20
MaterialPolycrystalline Cubic Boron Nitride (PCBN)
CoatingTiCN
Description
The Tungaloy 6804794 is a DNGA 32H polycrystalline cubic boron nitride (pcbn) indexable insert, grade BXM20, TiCN coated. Suited for hard material.
Specifications
Chip breakerH
Clearance codeN
Coating finishTiCN
Coating processPVD
Corner radius in1/32
Cutting edge styleChamfered & Honed
Full radiusNo
Hole diameter0.2030
Included angle55degree
Industry standard number2QP-DNGA 432-H
Inscribed circle in1/2
Insert handNeutral
Insert holding methodClamp; Pin
Insert length1.2200
Insert materialPolycrystalline Cubic Boron Nitride (PCBN)
Insert shapeDiamond 55
Insert size code432
Insert styleDNGA
Insert thickness in3/16
Iso codeDNGA 32H
Length range0.7000 - 10.0000
Manufacturers catalog number6804794
Manufacturer gradeBXM20
Material gradeH10
Maximum depth of cut0.0197
Multi use applicationTurning; Facing; Boring; Back Turning; Back Boring
Multi use toolYes
Number of cutting edges2
Primary workpiece materialHard Material
RakeNegative
Rake angle0
Relief angle0
Single or multi tippedMulti Tipped
StandardsANSI; ISO
Tip length0.0830
Tolerance codeG
Width in1/2in
Wiper edgeNo
