Vlier
M6x1.0 Spring Plunger - Vlier SSLFM6
MFR# SSLFM6
$13.26List $16.35
Save 18%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
Supplier prices are confirmed before checkout. If one has changed since this page was updated, we show you the new price before you pay.
Request a quote- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Vlier SSLFM6 is a M6x1.0 stainless steel spring plunger.
Specifications
Body length10mm
Body length (mm)10.00
Final end force8.9N; 2lb
Final end force lb2.00
Final end force n8.90
Head diameter0.5in; 12.7mm
Head height0.27in; 6.86mm
Initial end force2.22N; 0.5lb
Initial end force lb0.50
Initial end force n2.22
Knob styleKnurled
Length under head shoulder0.5300
Locking elementNo
MaterialStainless Steel
Maximum plunger diameter0.1200
Plunger length0.8000
Plunger projection0.1300
Plunger typeLocking
Thread length0.4in; 10.16mm
Thread sizeM6x1.0
