LPMT150412R-D51 WKP35S Solid Carbide Insert, Grade WKP35S, TiCN - Walter 5918284

Walter

LPMT150412R-D51 WKP35S Solid Carbide Insert, Grade WKP35S, TiCN - Walter 5918284

MFR# 5918284ISO/ANSI# LPMT150412R-D51 WKP35SCat# LPMT150412R-D51Series LPMT

$26.52List $34.02 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC1/2
ShapeRectangle
GradeWKP35S
MaterialSolid Carbide
CoatingTiCN

Description

The Walter 5918284 is a LPMT150412R-D51 WKP35S solid carbide indexable insert, grade WKP35S, TiCN coated. Suited for steel, cast iron.

Specifications

Ansi codeLPMT150412R-D51 WKP35S
Chip breakerD51
Coating finishTiCN
Coating processCVD
Corner radius in3/64
Cutting edge styleHoned
Included angle degree90
Inscribed circle in1/2
Inscribed circle range0.5000 to 0.5100
Insert handRight Hand
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeRectangle
Insert size15
Insert size code150412
Insert styleLPMT
Iso codeLPMT150412R-D51 WKP35S
Length in5/8
Length range0.6000 to 0.6500
Manufacturers catalog numberLPMT150412R-D51
Manufacturer gradeWKP35S
Material applicationSteel; Cast Iron
Material gradeP35; K35
Maximum depth of cut0.6250
Multi use toolYes
Number of cutting edges2
Primary workpiece materialSteel; Cast Iron
RakePositive
Rake angle10
Relief angle11
Single or double sided insertSingle
StandardsANSI; ISO
Thickness in3/16
Thickness range0.1850 to 0.2000
Width in1/2
